◆入力電圧範囲Edc |
18～36V, 36～76V |
| ◆使用温度範囲 |
-40～+100℃(ディレーティングが条件により異なります) |
| ◆耐圧Eac/dc |
入力-出力間 1.5Kv.1min[カットアウ電流ト20mA] |
|
入力-ベースプレート間 1.5Kv.1min[カットアウト電流20mA] |
|
出力-べースプレート間 DC500v.1min |
| ◆付属機能 |
過電圧保護 過電流保護 過熱保護 |
|
リモートON/OFFコントロール, リモートセンシング |
| ◆安全規格 |
UL,CSA,EN認定 |
|
タイプにより認可規格が異なります。詳細はカタログ参照ください。 |
|
CEマーキング適合 |
| ◆環境対応 |
RoHS指令対応 |
| ◆詳しい資料 |
カタログ |
|
|
|
| 製品仕様 |
出力電力
(W) |
型名
|
入力電圧
dc(V) |
CH |
出力電圧
(V) |
出力電流
(A) |
Peak電流
(A) |
寸法(WxHxD)
(mm) |
質量
(g) |
受注数量
(min) |
単価
(円) |
| 50 |
PAH50S48-2.5 |
36～76 |
- |
2.5 |
11.7 |
- |
57.9 x 12.7 x 61 |
80 |
1 |
|
| PAH50S48-3.3 |
- |
3.3 |
11.7 |
- |
1 |
|
| PAH50S48-5 |
- |
5.0 |
10 |
- |
1 |
|
| PAH50S48-12 |
- |
12 |
4.2 |
- |
1 |
|
| PAH50S48-15 |
- |
15 |
3.4 |
- |
1 |
|
| PAH50S48-24 |
- |
24 |
2.1 |
- |
1 |
|
| PAH50S48-28 |
- |
28 |
1.8 |
- |
1 |
|
| 75 |
PAH75S48-2.5 |
36～76 |
- |
2.5 |
17.5 |
- |
57.9 x 12.7 x 61 |
80 |
1 |
|
| PAH75S48-3.3 |
- |
3.3 |
17.5 |
- |
1 |
|
| PAH75S48-5 |
- |
5 |
15.0 |
- |
1 |
|
| PAH75S48-12 |
- |
12 |
6.3 |
- |
1 |
|
| PAH75S48-15 |
- |
15 |
5.0 |
- |
1 |
|
| PAH75S48-24 |
- |
24 |
3.2 |
- |
1 |
|
| PAH75S48-28 |
- |
28 |
2.7 |
- |
1 |
|
| 75 |
PAH75D24-3325 |
18～36 |
Vo1 |
3.3 |
15.0 |
- |
57.9 x 12.7 x 61 |
80 |
1 |
|
| Vo2 |
2.5 |
15.0 |
- |
| PAH75D24-5033 |
Vo1 |
5.0 |
15.0 |
- |
1 |
|
| Vo2 |
3.3 |
15.0 |
- |
| PAH75D48-2518 |
36～76 |
Vo1 |
2.5 |
15.0 |
- |
1 |
|
| Vo2 |
1.8 |
15.0 |
- |
| PAH75D483-3118 |
Vo1 |
3.3 |
15.0 |
- |
1 |
|
| Vo2 |
1.8 |
15.0 |
- |
| PAH75D48-3325 |
Vo1 |
3.3 |
15.0 |
- |
1 |
|
| Vo2 |
2.5 |
15.0 |
- |
| PAH75D48-5033 |
Vo1 |
5.0 |
15.0 |
- |
1 |
|
| Vo2 |
3.3 |
15.0 |
- |
| 100 |
PAH100S48-2.5 |
36～76 |
- |
2.5 |
23.4 |
- |
57.9 x 12.7 x 61 |
80 |
1 |
|
| PAH100S48-3.3 |
- |
3.3 |
23.4 |
- |
1 |
|
| PAH100S48-5 |
- |
5 |
20.0 |
- |
1 |
|
| PAH100S48-12 |
- |
12 |
8.4 |
- |
1 |
|
| PAH100S48-15 |
- |
15 |
6.7 |
- |
1 |
|
| PAH100S48-24 |
- |
24 |
4.2 |
- |
1 |
|
| PAH100S48-28 |
- |
28 |
3.6 |
- |
1 |
|
| 150 |
PAH150S48-2.5 |
36～76 |
- |
2.5 |
35.0 |
- |
57.9 x 12.7 x 61 |
80 |
1 |
|
| PAH150S48-3.3 |
- |
3.3 |
35.0 |
- |
1 |
|
| PAH150S48-5 |
- |
5 |
30.0 |
- |
1 |
|
| PAH150S48-12 |
- |
12 |
12.5 |
- |
1 |
|
| PAH150S48-15 |
- |
15 |
10.0 |
- |
1 |
|
| PAH150S48-24 |
- |
24 |
6.3 |
- |
1 |
|
| PAH150S48-28 |
- |
28 |
5.4 |
- |
1 |
|
| PAH150S48-48 |
- |
48 |
3.2 |
- |
1 |
|
| 200 |
PAH200S48-12 |
36～76 |
- |
12 |
16.7 |
- |
57.9 x 12.7 x 61 |
80 |
1 |
|
| PAH200S48-15 |
- |
15 |
13.4 |
- |
1 |
|
| PAH200S48-24 |
- |
24 |
8.4 |
- |
1 |
|
| PAH200S48-28 |
- |
28 |
7.2 |
- |
1 |
|
| 200 |
PAH200H48-1R2 |
36～76 |
- |
1.2 |
70.0 |
- |
61 x 10.2 x 57.9 |
90 |
1 |
|
| PAH200H48-1R5 |
- |
1.5 |
70.0 |
- |
1 |
|
| PAH200H48-1R8 |
- |
1.8 |
70.0 |
- |
1 |
|
| PAH200H48-2R5 |
- |
2.5 |
70.0 |
- |
1 |
|
| PAH200H48-3R3 |
- |
3.3 |
60.0 |
- |
1 |
|
| 300 |
PAH300S24-12 |
18～36 |
- |
12 |
25.0 |
- |
61 x 10.2 x 57.9 |
90 |
1 |
|
| PAH300S24-28 |
- |
28 |
11.0 |
- |
1 |
|
| 300 |
PAH300S48-12 |
36～76 |
- |
12 |
25.0 |
- |
61 x 12.7 x 57.9 |
90 |
1 |
|
| PAH300S48-28 |
- |
28 |
11.0 |
- |
1 |
|
| 350 |
PAH350S24-28 |
18～36 |
- |
28 |
12.5 |
- |
61 x 12.7 x 57.9 |
100 |
1 |
|
| 350 |
PAH350S48-12 |
36～76 |
- |
12 |
29.2 |
- |
61 x 12.7 x 57.9 |
100 |
1 |
|
| PAH350S48-28 |
- |
28 |
12.5 |
- |
1 |
|
| 450 |
PAH450S48-28 |
36～76 |
- |
28 |
16.0 |
- |
61 x 12.7 x 57.9 |
100 |
1 |
|
| PAH450S48-48 |
- |
48 |
4.9 |
- |
1 |
|
|
|
|
